Available to Order
Manufacturer Standard Lead Time: 14 week(s)
| Quantity | Price |
|---|---|
| 5+ | $36.820 |
| 10+ | $35.910 |
| 25+ | $35.010 |
| 50+ | $32.630 |
| 100+ | $31.260 |
| 250+ | $29.890 |
Price for:Each
Minimum: 5
Multiple: 1
$184.10
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerEAO
Manufacturer Part No19-289.015
Newark Part No.30B4013
Product Range19 Series
Technical Datasheet
Pushbutton Switch TypeStandard
Product Range19 Series
Panel Cutout Diameter8mm
Contact ConfigurationSPST-NO
Switch OperationMaintained
Pushbutton Actuator StyleSquare
Actuator / Cap Colour-
Contact Current AC Max800mA
Contact Current Max800mA
Contact Voltage AC Nom50V
Contact Voltage VAC50V
Contact Current DC Max-
Contact Voltage DC Nom72V
Contact Voltage VDC-
IP RatingIP40
Switch MountingPanel Mount
Switch TerminalsQuick Connect
Panel Cutout (H x W)-
SVHCNo SVHC (17-Jan-2023)
Product Overview
The 19-289.015 is an illuminated Pushbutton Actuator with solder terminals. This Ø8mm cut-out mounting actuator has 9 x 9mm red square front shape. This maintained actuator features 1 NO snap-action switching element and silver contacts.
- IP40 Front protection rating
Applications
Industrial
Technical Specifications
Pushbutton Switch Type
Standard
Panel Cutout Diameter
8mm
Switch Operation
Maintained
Actuator / Cap Colour
-
Contact Current Max
800mA
Contact Voltage VAC
50V
Contact Voltage DC Nom
72V
IP Rating
IP40
Switch Terminals
Quick Connect
SVHC
No SVHC (17-Jan-2023)
Product Range
19 Series
Contact Configuration
SPST-NO
Pushbutton Actuator Style
Square
Contact Current AC Max
800mA
Contact Voltage AC Nom
50V
Contact Current DC Max
-
Contact Voltage VDC
-
Switch Mounting
Panel Mount
Panel Cutout (H x W)
-
Technical Docs (1)
Associated Products
2 Products Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (17-Jan-2023)
