Product Information
ManufacturerEAO
Manufacturer Part No51-425.036
Newark Part No.66F9705
Product Range51 Series
Technical Datasheet
Product Range51 Series
Pushbutton Switch TypeStandard
Panel Cutout Diameter16.2mm
Contact ConfigurationSPST-NO
Contact Current Max100mA
Switch OperationMomentary
Pushbutton Actuator StyleRectangular
Contact Voltage AC Nom42V
Actuator / Cap Colour-
Contact Voltage DC Nom42V
Contact Current AC Max100mA
Contact Voltage VAC42V
Contact Current DC Max100mA
Contact Voltage VDC42V
IP RatingIP65
Switch MountingPanel Mount
Switch TerminalsPC Pin
Illumination Color-
Panel Cutout (H x W)-
SVHCNo SVHC (17-Jan-2023)
Product Overview
The 51-425.036 is a single-pole single-throw (SPST) illuminated Pushbutton Switch with a polyetherimide rectangular actuator and universal terminal. The 51 series switch equipped with low level switching elements, momentary function and 1NO contact. It has gold-plated contact. The universal terminals permit these units to be mounted on printed circuit boards (PCB).
- Raised mounting design
- Extremely short rebound time and stable contact resistance
- 2.0 x 0.5mm Terminals
Applications
Motor Drive & Control, Industrial
Technical Specifications
Product Range
51 Series
Panel Cutout Diameter
16.2mm
Contact Current Max
100mA
Pushbutton Actuator Style
Rectangular
Actuator / Cap Colour
-
Contact Current AC Max
100mA
Contact Current DC Max
100mA
IP Rating
IP65
Switch Terminals
PC Pin
Panel Cutout (H x W)
-
Pushbutton Switch Type
Standard
Contact Configuration
SPST-NO
Switch Operation
Momentary
Contact Voltage AC Nom
42V
Contact Voltage DC Nom
42V
Contact Voltage VAC
42V
Contact Voltage VDC
42V
Switch Mounting
Panel Mount
Illumination Color
-
SVHC
No SVHC (17-Jan-2023)
Technical Docs (1)
Associated Products
5 Products Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (17-Jan-2023)
