Available to Order
Manufacturer Standard Lead Time: 41 week(s)
| Quantity | Price |
|---|---|
| 100+ | $13.990 |
| 250+ | $13.060 |
Price for:Each
Minimum: 100
Multiple: 50
$1,399.00
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerHONEYWELL
Manufacturer Part NoWA-2RV313-A22
Newark Part No.39B3065
Product RangeWA Series
Technical Datasheet
Microswitch TypeStandard
Microswitch ActuatorStraight Lever
Contact ConfigurationSPST-NC
Switch TerminalsScrew
Contact Current Max20A
Contact Voltage DC Nom-
Product RangeWA Series
Contact Voltage AC Nom250V
Operating Force Max6.12N
SVHCNo SVHC (07-Jul-2017)
Product Overview
The WA-2RV313-A22 is a MICRO SWITCH™ premium large Basic Switch with pin plunger actuator, silver contacts and screw termination. It is used for precision on/off applications, irrigation systems, semi-trailer trucks, timing devices, office equipment, manually operated devices and valves.
- Low operating force and differential travel
- Long mechanical life up to 20,000,000 cycles at 95% survival
- Elongated mounting hole for easier, more accurate mounting
- UL, CSA, ENEC and CE Certified
Applications
Agriculture, Medical, Test & Measurement, HVAC
Technical Specifications
Microswitch Type
Standard
Contact Configuration
SPST-NC
Contact Current Max
20A
Product Range
WA Series
Operating Force Max
6.12N
Microswitch Actuator
Straight Lever
Switch Terminals
Screw
Contact Voltage DC Nom
-
Contact Voltage AC Nom
250V
SVHC
No SVHC (07-Jul-2017)
Technical Docs (2)
Associated Products
1 Product Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Y-Ex
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (07-Jul-2017)
