Our range of single band chip antennas has choices for operating frequency, antenna case size, and packaging. We have products from over a dozen suppliers.Essential selection criteria for single band chip antennas include their operating frequency – which dictates their application – and their PCB mounting type.

Applications and operating frequencies:

Bluetooth and ZigBee operate at 2.4GHz.Wi-Fi operates at 5.5GHz single band (and 2.4/5.5Ghz dual band)The ISM (Industrial, Scientific and Medical) frequencies cover 400MHz, 783MHz, 888MHz, 915MHz, and 900MHz (868+915). ISM applications include cordless phones, near-field communication (NFC) devices, garage door openers, and baby monitors, GPS and Galileo operate at 1.575 -1.602GHz, and 1.227GHz.WiMAX operates at 2.5 and 2.6GHz. WiMAX data rates can scale easily with available channel bandwidth, making it suitable for applications such as providing a wireless alternative to cable and DSL lines for ‘last mile’ broadband access. Ultra-wideband (UWB) operates at 3.1 – 10.3GHz. It can use a very low energy level for short-range, high-bandwidth communications over a wide radio spectrum. Applications include sensor data collection, precise locating, and tracking.Chip Antenna PCB mounting optionsChip Antenna PCB mounting options include Corner Mounting, Centre-Edge Mounting, and End Mounting. Circular PCB mounting options are also possible.

			Price for		Quantity

ANT3216LL00R6580A	28AK5569 Data Sheet RoHS Date/Lot Code	PULSE ELECTRONICS CERAMIC ANTENNA 7200MHZ LINEAR ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.639 10+ $0.578 25+ $0.531 50+ $0.475 100+ $0.429 More Pricing...	Min: 5 / Mult: 5	7.2GHz	3216	SMD Chip Antenna
AANI-CH-0131-Q-T	25AM0084 RoHS Date/Lot Code	ABRACON CHIP ANTENNA 2.45GHZ 4.6DBI LINEAR ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.675 10+ $0.610 25+ $0.560 50+ $0.502 100+ $0.452 More Pricing...	Min: 1 / Mult: 1	2.45GHz	3.2mm x 1.6mm x 1.2mm	-
ANT5320LL14R1575A	16AM5023 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 1.575GHZ 3.16DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.060 10+ $0.945 25+ $0.882 50+ $0.817 100+ $0.753 More Pricing...	Min: 1 / Mult: 1	1.575GHz	5.3mm x 2mm x 1.2mm	SMD Chip Antenna
ANT7836LL15R2400A	16AM5026 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 2.45GHZ 4.1DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.690 10+ $0.616 25+ $0.572 50+ $0.528 100+ $0.484 More Pricing...	Min: 1 / Mult: 1	2.45GHz	7.8mm x 3.6mm x 0.9mm	SMD Chip Antenna
7488920157	58AK2141 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK CHIP ANTENNA 1.575GHZ 50 OHM ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.420 10+ $1.290 25+ $1.250 50+ $1.190 100+ $1.150	Min: 1 / Mult: 1	1.575GHz	5.2mm x 3.7mm x 0.7mm	WE-MCA Series
ANT7020LL05R0870A	16AM5024 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 870MHZ 1.83DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.504 10+ $0.365 25+ $0.329 50+ $0.311 100+ $0.291	Min: 1 / Mult: 1	870MHz	7mm x 2.05mm x 0.78mm	SMD Chip Antenna
ANT1204LL20R0433A	16AM5018 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 433MHZ 0.83DBI ISM ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $3.250 10+ $1.920 25+ $1.810 50+ $1.690 100+ $1.580 More Pricing...	Min: 1 / Mult: 1	433MHz	1204	SMD Chip Antenna
2450AT18D0100002E	01AM9739 RoHS	JOHANSON TECHNOLOGY ANTENNA 2.45GHZ 1.5DBI 50 OHM SMD ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.773 10+ $0.556 25+ $0.501 50+ $0.471 100+ $0.442 More Pricing...	Min: 1 / Mult: 1	2.45GHz	3.2mm x 1.6mm x 1.2mm	-
ANT1204F007R0870A	16AM5015 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 870MHZ 1.67DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.800 10+ $1.300 25+ $1.180 50+ $1.050 100+ $0.922 More Pricing...	Min: 1 / Mult: 1	870MHz	12.2mm x 4mm x 1.6mm	SMD Chip Antenna
ANT5320LL45R2400A	62AK3685 Data Sheet RoHS Date/Lot Code	PULSE ELECTRONICS CERAMIC HELIX CHIP ANTENNA 2.4GHZ 5320 ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.483 10+ $0.348 25+ $0.314 50+ $0.296 100+ $0.278	Min: 1 / Mult: 1	2.4GHz	5320	SMD Chip Antenna
ANT8010LL05R1516A	16AM5027 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 1.602GHZ 1.69DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.418 10+ $0.297 25+ $0.269 50+ $0.252 100+ $0.236	Min: 5 / Mult: 5	1.602GHz	8010	SMD Chip Antenna
AANI-CH-0131-T	25AM0085 RoHS Date/Lot Code	ABRACON CHIP ANTENNA 2.45GHZ 4.6DBI LINEAR ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.587 10+ $0.530 25+ $0.488 50+ $0.436 100+ $0.394 More Pricing...	Min: 5 / Mult: 5	2.45GHz	3.2mm x 1.6mm x 1.2mm	-
RFANT1005040A1T	29AK4703 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Chip Antenna 2.4 GHz ISM Band 1 mm x 0.5mm x 0.4mm	Each (Supplied on Cut Tape) Cut Tape	1+ $0.785 10+ $0.689 25+ $0.605 50+ $0.506 100+ $0.426 More Pricing...	Min: 5 / Mult: 5	2.4GHz	1 mm x 0.5mm x 0.4mm	RFANT Series
AANI-CH-0070	03AM7482 Data Sheet RoHS Date/Lot Code	ABRACON CERAMIC CHIP ANTENNA 2.45GHZ 1.7DBI ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.753 10+ $0.383 25+ $0.341 50+ $0.300 100+ $0.258 More Pricing...	Min: 5 / Mult: 5	2.45GHz	1mm x 0.5mm x 0.4mm	-
74889302450	30AK3722 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK CHIP ANTENNA 2.45GHZ 3.2MMX1.6MMX1.2MM ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.943 10+ $0.942 25+ $0.904 50+ $0.864 100+ $0.826 More Pricing...	Min: 1 / Mult: 1	2.45GHz	3.2mm x 1.6mm x 1.2mm	WE-MCA Series
L000601-80	07AM0159 RoHS	TE CONNECTIVITY EMBEDDED CHIP ANTENNA 7GHZ 3.7DBI UWB ROHS COMPLIANT: YES	Each	1+ $62.660	Min: 1 / Mult: 1	7GHz	6mm x 5mm x 0.5mm	-
ANT161575ST-1202A1	70AK2034 Data Sheet RoHS Date/Lot Code	TDK CHIP ANTENNA 1.557-1.605GHZ MULTILAYER ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.549 10+ $0.398 25+ $0.372 50+ $0.347 100+ $0.324 More Pricing...	Min: 1 / Mult: 1	1.581GHz	1.6mm x 0.8mm x 0.4mm	-
L000601-01	04AM1209 RoHS Date/Lot Code	TE CONNECTIVITY EMBEDDED CHIP ANTENNA 3.7DBI UWB 10W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.840 10+ $1.260 25+ $1.100 50+ $1.010 100+ $0.929	Min: 1 / Mult: 1	7GHz	6mm x 5mm x 0.5mm	-
AMCA31-2R450G-S1F-T3-Q	25AM5203 RoHS Date/Lot Code	ABRACON CHIP ANTENNA 2.45GHZ 2.3DBI LINEAR ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.040 10+ $0.650 25+ $0.537 50+ $0.481 100+ $0.423 More Pricing...	Min: 1 / Mult: 1	2.45GHz	3.2mm x 1.6mm x 1.2mm	-
RFANT8060101YAT	78AK8110 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Ceramic Chip Antenna 6.5GHz 4.5dBi 8mm x 6mm x 1mm	Each (Supplied on Cut Tape) Cut Tape	1+ $1.610 10+ $1.530 25+ $1.420 50+ $1.290 100+ $1.160 More Pricing...	Min: 1 / Mult: 1	6.5GHz	8mm x 6mm x 1mm	RFANT Series
ANT1204F002R0315A	16AM5012 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 315MHZ ISM 1W 50 OHM ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.490 10+ $1.100 25+ $1.010 50+ $0.949 100+ $0.896 More Pricing...	Min: 1 / Mult: 1	315MHz	12.3mm x 4mm x 1.6mm	SMD Chip Antenna
7488960245	58AK2143 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK CHIP ANTENNA 2.45GHZ 50 OHM ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.570 10+ $1.420 25+ $1.370 50+ $1.320 100+ $1.270	Min: 1 / Mult: 1	2.45GHz	5.2mm x 3.7mm x 0.7mm	WE-MCA Series
ANT1204F005R0915A	16AM5014 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 915MHZ 1.59DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $1.200 10+ $1.050 25+ $0.943 50+ $0.841 100+ $0.737 More Pricing...	Min: 1 / Mult: 1	915MHz	1204	SMD Chip Antenna
W3012	63AK2072 Data Sheet RoHS	PULSE ELECTRONICS CERAMIC ANTENNA 900MHZ ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $3.280 10+ $1.870 25+ $1.770 50+ $1.670 100+ $1.570 More Pricing...	Min: 1 / Mult: 1	900MHz	10mm x 3.2mm x 4mm	-
ANT7020LL05R2400A	16AM5025 RoHS Date/Lot Code	PULSE ELECTRONICS CHIP ANTENNA 2.45GHZ 2.62DBI 1W ROHS COMPLIANT: YES	Each (Supplied on Cut Tape) Cut Tape	1+ $0.647 10+ $0.642 25+ $0.591 50+ $0.541 100+ $0.490 More Pricing...	Min: 5 / Mult: 5	2.45GHz	7020	SMD Chip Antenna
